- Amps: 7.15/3.6
- Bearings: Ball
- Duty Cycle: Continuous
- Enclosure Material: Rolled Steel
- Enclosure Type: ODP (Open Dripproof)
- Frame: 184T
- HP: 2
- Hz: 60
- Insulation Class: F
- Manufacturer Model : E207M2
- Maximum Ambient Temperature: 40° C
- Motor Shell Length: 11″
- Mounting: Base
- Overall Length: 15.19″
- Phase: 3
- Product Type: Three Phase
- Rotation: Reversible
- RPM: 1180
- Service Factor: 1.15
- Shaft Diameter: 1-1/8″
- Shaft Length: 2.81
- Volts: 230
- Volts: 460
- Ship Weight: 95 lbs.
