Century H847 General Purpose Three Phase Motor – H847

Original price was: $396.23.Current price is: $291.86.

Sale!
SKU: H847 Category:
Share
  • Product Type: 3 Phase
  • HP: 5
  • RPM: 3450
  • Volts: 208-230/460
  • Amps: 6.6/13.4/13.2
  • Hz: 60
  • Phase: 3
  • Frame: 56HZ
  • Enclosure Type: ODP (Open Dripproof)
  • Mounting: Rigid
  • Motor Diameter: 6-1/2″
  • Shaft Diameter: 7/8″ Keyed
  • Shaft Length: 2-5/16″
  • Rotation: Reversible
  • Number of Speeds: 1
  • Service Factor (SF): 1.15
  • Bearings: Ball
  • Thermal Protection: Automatic
  • Maximum Ambient Temperature: 40° C
  • Insulation Class: B
  • Duty Cycle: Continuous
  • H847 is listed in Century’s cross reference as a possible substitute for the following: A.O. Smith 164724, A.O. Smith 313P285, A.O. Smith BR3502, A.O. Smith P56P2T8B4, A.O. Smith P56R2T8B9, Carrier/BDP HD60AZ660, Century 164724, Leeson 114623, Marathon X251, Trane 3082, Trane MOT 3082, A.O. Smith BK3502, A.O. Smith P56R2T11B9, Century H846
  • Ship Weight: 44 lbs.
