Ko-ken 13103M-7(1.0) 3/8 Sq. Dr. Stud Bolt Setter M7 X 1.0 Length 32mm
The 3/8″ drive, stud setter Stud Bolt Setter is a special socket for installing a stud bolt. The bolt contact with a steel ball to prevent the bolt from sticking onto the socket. After installing the bolt, turn anti-clockwise to remove the socket.
Product Specifications
- Drive Shape: Square
- Input Drive Size: 3/8″
- Length: 32mm
- Output Size: M7 x 1.0
- Type: Stud Bolt Setter
- Note: Depend on the stud bolt and using torque, 4103M/13103M/14103M may cause a scratch against the stud bolts or got stuck itself during a work
- Product Dimension (Refer Line Drawing Image):
- D1 Size: 12.5mm
- D2 Size: 19mm
- H Size: 10mm
- L Size: 32mm
