- Product Type: Capacitor Start
- HP: 1/2
- RPM: 1725
- Volts: 115/208-230
- Amps: 8.0/4.0-4.0
- Hz: 60
- Phase: 1
- Frame: 56
- Enclosure Type: TEFC (Totally Enclosed Fan Cooled)
- Enclosure Material: Rolled Steel
- Mounting: Rigid Base
- Shaft Diameter: 0.625″
- Shaft Length: 1.88″
- Motor Shell Length: 6.25″
- Overall Length: 11.22″
- Rotation: Reversible
- Number of Speeds: 1
- Service Factor: 1.15
- Bearings: Ball
- Efficiency: 66.0%
- Maximum Ambient Temperature: 40° C
- Insulation Class: B
- Duty Cycle: Continuous
- Ship Weight: 24 lbs.
Leeson LM24627 Capacitor Start General Purpose Motor
Original price was: $75.81.$45.71Current price is: $45.71.
