FIA-Certified Carbon Fiber Racing Seat Born from OMP’s HTE ONE Championship Platform
The OMP HA0-0817-A01-071 HTE-EVO Carbon Racing Seat is a lightweight, FIA 8855-1999 homologated bucket seat built around the same innovative shell architecture as the HTE ONE. Constructed with a carbon fiber shell, the HA0-0817-A01-071 features AIRNET breathable fabric and velvet upholstery for sustained comfort during extended motorsport use. Side-mounted with five harness holes, it is compatible with HANS devices and approved for use in FIA-sanctioned competition through the homologation expiry year. The OMP HA0-0817-A01-071 is sold as a single seat.
Key Features
- Carbon fiber shell for maximum strength with minimal weight
- FIA 8855-1999 homologated for use in sanctioned motorsport competition
- HANS-compatible shoulder slot design for use with head and neck restraint systems
- AIRNET breathable fabric and velvet upholstery for improved airflow and comfort
- 5 harness holes for 4-point, 5-point, or 6-point harness systems
- Side mounting (Type W) with 289mm inner side spacing
- Large shoulder harness slots designed to accommodate varying harness heights
- Total seat width: 590mm; total seat height: 900mm; external seat bottom width: 450mm
- Seat shell weight: approximately 7.5 kg (16.5 lbs)
- Anti-counterfeiting hologram included with FIA homologation documentation
Specifications
| Detail | Value |
|---|---|
| Part Number | HA0-0817-A01-071 |
| Brand | OMP |
| Series | HTE-EVO |
| Shell Material | Carbon Fiber |
| Upholstery | AIRNET Fabric and Velvet |
| Homologation | FIA 8855-1999 |
| HANS Compatible | Yes |
| Harness Holes | 5 |
| Mounting Style | Side (Type W, 289mm inner spacing) |
| Total Width (A) | 590 mm |
| Total Height (D) | 900 mm |
| External Bottom Width (C) | 450 mm |
| Shell Weight | Approx. 7.5 kg (16.5 lbs) |
| Color | Black |
| Sold As | Single seat |
| UPC | N/A |
What’s Included
- 1x OMP HA0-0817-A01-071 HTE-EVO Carbon Racing Seat
- FIA homologation card with anti-counterfeiting hologram
- Mounting hardware not included (seat brackets sold separately)
Frequently Asked Questions
Is the OMP HTE-EVO Carbon seat FIA approved for competition use?
Yes. The HA0-0817-A01-071 is FIA 8855-1999 homologated and approved for use in FIA-sanctioned motorsport events. Each seat ships with a homologation card and anti-counterfeiting hologram. FIA 8855-1999 homologation is subject to an expiry per calendar year as published by the FIA.
What harness systems are compatible with the OMP HTE-EVO Carbon?
The HA0-0817-A01-071 features 5 harness holes and is compatible with 4-point, 5-point, and 6-point harness systems. The shoulder slots are designed for use with HANS head and neck restraint devices in compliance with FIA regulations.
What is the difference between the OMP HTE-EVO Carbon and the HTE-EVO Fiberglass?
Both seats share the same HTE-EVO shell shape and FIA 8855-1999 homologation. The Carbon version uses a carbon fiber shell which is lighter than the fiberglass version. The fiberglass seat is a more accessible option while the carbon seat delivers maximum weight savings for competitive motorsport use.
What mounting brackets are required for the OMP HTE-EVO Carbon seat?
The HA0-0817-A01-071 uses side mounting (Type W) with an inner spacing of 289mm. OMP offers a range of vehicle-specific seat rail brackets. Per FIA regulations, the seat must be secured with a minimum of four M8 grade 8.8 bolts through the mounting points.
What are the key dimensions of the OMP HTE-EVO Carbon seat?
The seat has a total external shoulder width of 590mm, a total back height of 900mm, and an external bottom width of 450mm. The seat back height from bottom to harness slot is approximately 380mm. These are guideline measurements; actual production dimensions may vary slightly.
What is the weight of the OMP HTE-EVO Carbon seat shell?
The carbon shell weighs approximately 7.5 kg (16.5 lbs). FIA 8855-1999 weight figures refer to the complete seat with a tolerance of 10 percent.
Is the OMP HTE-EVO Carbon seat legal for street use?
The HA0-0817-A01-071 is a competition racing seat designed for closed-course motorsport use. Street legality varies by jurisdiction. Consult local regulations before installing any competition seat in a street-registered vehicle.
Does the OMP HTE-EVO Carbon seat come with mounting hardware?
No. Mounting brackets and seat rails are sold separately. OMP offers vehicle-specific mounting solutions compatible with the Type W side mount pattern. Confirm the correct bracket set for your vehicle before ordering.
Installation Notes
- Select OMP-compatible side mount brackets (Type W, 289mm) specific to your vehicle application
- Remove the factory seat and disconnect all wiring (airbag, seat sensor) per your vehicle service manual
- Secure the seat to brackets using four M8 grade 8.8 bolts at minimum as required by FIA regulations
- Install a minimum 4-point harness through the seat harness slots before use in competition
- Verify HANS device compatibility before each competition event
- Confirm FIA homologation card is present and current before use in sanctioned events
WARNING: This product can expose you to chemicals including lead and phthalates, which are known to the State of California to cause cancer and reproductive harm. For more information go to www.P65Warnings.ca.gov.
